| Code | Code | Inner & Outer Dia. (mm.) | Coil Size (mt.) | |
| Metric | NPT | |||
| OPGSC7-LS | 12 | 7,5-11,5 | 50 | |
| OPGSC9-LS | 16 | 1/4′ | 9-13 | 50 |
| OPGSC11-LS | 16 | 3/8′ | 11-15 | 50 |
| OPGSC16-LS | 20 | 1/2′ | 16-20 | 50 |
| OPGSC21-LS | 25 | 3/4′ | 21-25 | 50 |
| OPGSC26-LS | 32 | 1′ | 26-31 | 25 |
| OPGSC35-LS | 1 1/4′ | 35-40 | 25 | |
| OPGSC37-LS | 40 | 37-42 | 25 | |
| OPGSC40-LS | 50 | 1 1/2′ | 40-45 | 25 |
| OPGSC51-LS | 63 | 2′ | 51-56 | 25 |
| OPGSC63-LS | 2 1/2′ | 63-68 | 25 | |
| OPGSC75-LS | 3′ | 75-83 | 25 | |
- This product can also be supplied with a draw wire. Please add “dw” after part code.
- Other coil sizes available upon request.Please add requested coil size after part code.
